Price:Negotiable
Brand:ZKJD
Quantity:100000

Send Inquiry

Specification
NO Items Specs
1 Sizes and weight 94.1x99x50;480g
2 Dimension of inlet 20mm(1/2 inch thread)
3 Dimension of outlet 20mm(1/2 inch thread)
4 Driving method Brushless, Magnetic , 2 phase or 3 phase
5 Pump material PA66+GF30% (optional)
6 Condition of use Continuously
7 Fluids Water, oil, acid and alkali solution etc
8 Max working temp 60 Celsius(2 phase)or 100 Celsius(3 phase)
9 Power consumption 2.5W~43.2W(2 phase) 2.5W~86.4W(3 phase)
10 Rated voltage 12Vdc or 24Vdc
11 Voltage used 5Vdc ~ 12Vdc or 5Vdc ~ 24Vdc
12 Max rated current 1.8A(2 phase)or 3.6A(3 phase)
13 Max flow rate 17L/Min(4.5GPM) ---2 phase 20L/Min(5.5GPM) ---3 phase
14 Max Static Head 8m(26ft)---- 2 phase 15m(49ft)-- 3 phase
15 Noise <40dB
