Work table 700*1360mmTable load 1000 Kg
Longitudinal travel (X) 1200mm
Cross travel (Y) 700mm
Vertical travel(Z) 600mm
Spindle center to column surface 785mm
Spindle nose to table surface 150-750mm
ATC type Arm type
Magazine capacity 24PCS
T-slot (No-width*pitch) 5-18*152.5
Spindle taper BT50
Spindle speed 8000r/min
CNC Rotary table chuck diameter 320mm
CNC Rotary table spindle bore 70mm
Distance form CNC Rotary table to work table 355mm
CNC Rotary table T-slot width 14mm
A axis Max speed & travel 11rpm / +30°~-120°
C axis Max speed & travel 16rpm / ±360°
Main power 11kw
XYZ servo motor torque(NM) 16,20,20
Machine dimensions(L×W×H) 3750×3150×3000mm
Machine weight 8800kg
