Main Dimensions Length/Width/Height 10000mm*1680mm*2100mm Weight: 7200kg Grade ability: 14degree Speed: 2.5km/h Turning radius(inner/outer): 3750+-100/5660+-100mm Drilling range(Level-Parallel): 4.7m*4.9m(width/height) Area of Drilling Range(Level-Parallel): 23.03m2 Propeller Propelling stroke: 3.7m Compensation stroke: 1.25m Drill speed: 0.8-2m/min Drill rod length: 3.7m Drill depth(one stroke): 3.3m With the rock drill HYD300 Drill diameter: 38-89mm Drill speed: 200-400r/m Attack frequency: 30-50Hz Electrical system Power: 55Kw Voltage: AC380V/50HzElectric Hydraulic Rock Drilling Jumbo
2017-01-14 07:06 Views:201
Price:Negotiable
