Specifications Control System:PCB
Diameter of turntable:1500mm
Max pallet height:2100mm
Max pallet weight:2000kg
Film reel inside diameter:75mm
Film reel outside diameter:250mm
Turntable speed:1-10 cycles/Minute
Turntable height:80mm
Turntable motor:0.75kw
Film-rack lift motor:0.18kw
Power supply:220V 50HZ 1Phase
Features
1. Precise phase stopping at cycle end
2. Photocell to read pallet height
3. Pre-stretch rate up to 200%
4. Soft start and stop
5. Variable turntable speed
Options
1. Ramp
2. Pallet height
3. Turntable diameter
4. Machine color
Parameters adjustable from control panel
*Bottom pallet wrapping rounds from 1-10
*Top pallet wrapping rounds from 1-10
* Rotation speed adjustable from 3 to 10 rpm
