Specification overall weight(kg) 3600L×W×H(mm) 5100x1680x2650
Rated bucket capacity(m3) 0.5
Rated load(kg) 1200
dump height (mm) 2680
Dump distance 900mm
Wheelbase 2100mm
Tread 1400/1405mm
Total time 11s
Engine Brand and modle "Changchai 4L68
"
Type "Four strokes, Water cooling, Inline, injecting combustion chamber
"
Rated power(kw) 37
Rated speed(r/min) 2200
Working system Distribution of work valve DF15.2C
Working pump CBF32
Steering system Type Articulated hydraulic steering
Max. turning angle 27°±1°
Min turning radius(mm) 3500
Tire Standard tire "14/90-16,12-16.5
"
Optional wide tyres 14-17.5
