Max.turning diameter(mm) 700
Table diameter(mm)600
Max.working height of workpiece(mm) 700
Max.weight of workpiece(t) 1.2
Max.cutting resistance(KN.m) 20
Max.torque(KN.m) 10
Travel of railhead horizontal(mm)420
Travel of railhead Vertical(mm) 600
Speed range of table(r/min,8steps) 38/88,76/88,135/158,176/315
Feed range of railhead(m/min) 5-80,stepless
Rapid traveling speed of tool post(mm/min) 1800
Sectional size of tool bar(W*H)(mm) 30*40
Weight of machine(about t) 4.5
Power of feed motor(kw) 2.2
Power of main motor(kw) 11KW/1460r/min,14KW/2920r/min
Overall dimensions(L*W*H) 1938*1742*2700
