Price:Negotiable
Brand:JSWAY
Quantity:100

Send Inquiry

Max. swing over bed 380mm
Max machining diameter 300mm (pan type)/125mm(spindle type)
Max.lenght of machining 230mm
Spindle bore 56mm
Max.meterial diameter: 45mm
Spindle speed rating No rating
Spindle speed 100--4500 r/min
Upper part style of spindle flange / A2-5
Motor power: 4 KW
Tool post stypes/No. of tool positions 8 station Turret + 3 station drilling tool post
Turret tool changing method Turretstyle nearby tool changing
Tool changing time 0.3S
Tool changing accuracy 0.003mm
Max. travel of X-axis/Z-axis: 720/280mm
Min set unit 0.001mm
X-axis/Z fast moving speed 30M/Min
Reposition accuracy 0.003mm
Square knife size 20*20mm
Internal boring cutter size F20mm
Total installed capacity 6.5KW
Net weight 2500KG
Size 2040*1360*1800mm
