Spindle motor 3KW variable frequency motor
Spindle bearing Japan NSK P4
X/Z axis ball screw: Taiwan Hiwin/PMI C3
X/Z axis Screw bearing: Japan NSK P4
Hydrocylinder: whole cast-aluminum
Hydrocylinder: whole cast-aluminum
Tailstock None
Max. swing over bed 300mm
Max machining diameter 260mm (pan type)/77mm(spindle type)
Max.lenght of machining 200mm
Spindle bore 45mm
Max.meterial diameter: 35mm
Spindle speed rating No rating
Spindle speed 100--3500 r/min
Upper part style of spindle flange / A2-4
Motor power: 3 KW
Tool post stypes/No. of tool positions gang-type tool post/common tool post/8
Max. travel of X-axis/Z-axis: 630/230mm
Min set unit 0.001mm
X-axis/Z fast moving speed 18mm
Reposition accuracy 0.003mm
Square knife size 16*16mm
Internal boring cutter size F20mm
Total installed capacity 5.5KW
Net weight 2100KG
Size 2000*1400*1600 mm
