Horizontal Circle Foam Cutting Machine:The machine mainly puts many block foam on the worktable cutting slices at the same time, adopt fully automatic digital control, and setting the number as need cutting thickness and foam density by control box. The worktable runs automatically. The turning speed of worktable is adjustable. Continuously cutting ,the production efficiency is very high ( worktable also choose adding to vacuum equipment).
Model ERS-HC01/ERS- HC02/ERS- HC03
Cutting Foam Size:
L2000*W1500*H1200mm(4pcs) L2000*W1500*H1200mm(5pcs) L2000*W1500*H1200mm (8pcs)
Cutting Foam Thickness:
2-150mm 2-150mm 2-150mm
Worktable Turning Speed:
0-3.5r/min 0-3.5r/min 0-2.5r/min
Worktable Diameter:
?6m ?7m ?10.5m
Blade Length:
8940mm 10000mm 10240mm
Total Power:
8.12kw 8.92kw 10.52kw
Machine External Size:
L7000*W6500*H2500mm L7500*W7000*H2500mm L11500*W11000*H2500mm
