Brand:DVL(OEM allowed)
Quantity:1000
Send Inquiry
Technical data:Power supply: AC110220V±10%, 50/60HZ
Fuses: f5×20mm 250V 5A
Storage temperature: -15? to +50?
Operating temperature: 0? to 45?
Relative humidity: 0 to 90%
Dims of CCU.: 430x400x127mm
N.W. of CCU: 8.6kg
Safety standard: IEC601-1
Safety type: I/B
Camera:
CCD-sensor: 1/3” interline CCD×1 with micro lens and color mosaic filter
Resolution: 580 lines
Min sensitivity: 1 LUX(F1.2)
Video outputs: 1.0Vpp PAL(NTSC optional), 2xBNC,1xY/C
Signal/Noise ratio(S/N): 70dB
Shutter: 1/60s-1/10,000s
Balance/White(B/W): Auto/Manual
Opposite Retrieval: Auto
RGB: Auto
SPOT: Auto
Quick coupling: C-Mount
Adapter: 18/20/25/28/32S
Light Source:
Bulbs: 180 to 300 W Xenon or 30W to 100W LED bulb
Color temp.: approx.7000 K
Illumination: =5,800,000 Lx
Life cycle of xenon bulb: approx.500 h
Life cycle of LED bulb: approx.50,000 h
Light cable connection: DVL,STORZ,WOLF,OLYMPUS etc
