Brand:DVL(OEM allowed)
Quantity:1000
Send Inquiry
CCD-sensor: 1/3” interline CCD×1 with micro lens and color mosaic filter Visual field : 4.9(H)×3.7(V)
Resolution : 580 lines
Min sensitivity: 1 LUX(F2.0)
Video outputs: 1.0Vpp PAL , 75O,2xBNC, (NTSC,S-video optional)
Signal/Noise ratio(S/N): 70dB
Shutter: 1/60s-1/10,000s
Balance/White(B/W): Auto/Manual
Opposite Retrieval: Auto
RGB: Auto
SPOT: Auto
Quick coupling: C-Mount
Adapter: 18/20/25/28/32S
Power supply: AC110220V±10%, 50/60HZ
Fuses: f5×20mm 250V 2A
Safety standard: IEC601-1
Power consumption: approx.30 W
Storage temperature: -15? to +50?
Operating temperature: 0? to 45?
Relative humidity: 0 to 90%
Dims camera head: W: 28.8mm L: 68mm
Weight of camera head: approx.60g
Dims of CCU.: 300x300x93mm
N.W. of CCU: 2kg
