Brand:Tonhe
Quantity:5000
Send Inquiry
Technical Parameters:
Product size ?NPT/BSP 1/2"' ?NPT/BSP 3/4'' ?NPT/BSP 1" ?NPT/BSP 1 1/4'' (Optional )
Maximum working pressure 1.3 MPa
Circulation medium Fluid, air
Valve open /closed time = 7 seconds
Rated voltage ?AC/DC9-24V ?AC110-230V (Optional )
Keeping valve open time 0 H : 0M :0S --99 H 59
Keeping valve closed time 0 H : 0M :0S --99 H 59
Working current =500MA
Stall current setting 0-599mA
Life time 100000 times
Valve Body material ?Brass ?Nickel plated Brass ?304 Stainless steel (Optional)
Actuator material Engineering Plastics
Sealing material EPDM & PTFE
Actuator rotation 90°
Max. torque force 4N.M
Cable Length 0.5m,1.5m(Optional)
Environment temperature -15?~50?
Liquid temperature 2?~90?
Manual override No
Indicator Yes
Protection class IP67
