Price:Negotiable
Brand:CHAODA
Quantity:500

Send Inquiry

Working Area (X*Y*Z) 1220*2440*200mm / 1200*2400mm*200mm /1300*1800*200mm, 1500*3000*200mm
Max Moving Speed 30m/min
Max Engraving Speed 20m/min
Positioning Accuracy 0.05mm
Hold mode Vacuum/Clamp (vacuum table, Vacuum pump)
Spindle Speed 0-24000rpm/min
Spindle Power 4.5kw water cooling (option: 3kw water cooling, 4.5kw /6kw air cooling)
Tool Diameter ?2--?12.7
Transmission X,Y Axis High Precision Rack Gears, Z Axis Ball Screw
Driving Step motor (Option: Japan Servo Motor)
Voltage AC380V/50-60Hz
