Price:Negotiable
Brand:CHAODA
Quantity:600

Send Inquiry

Working Area (X*Y*Z) 1220*2440*250mm/1200*2400mm*250mm/1300*1800mm*250mm
Rotary Size 20cm diameters, 130cm length
Max Moving Speed 30m/min
Max Engraving Speed 20m/min
Positioning Accuracy 0.05mm
Hold mode Vacuum/Clamp (vacuum table, Vacuum pump)
Option system Dust collector system, dust cover
Spindle Speed 0-24000rpm/min
Spindle Power 4.5kw water cooling (option: 3kw water cooling, 4.5kw /6kw air cooling)
Tool Diameter ?2--?12.7
Transmission X,Y Axis High Precision Rack Gears, Z Axis Ball Screw
X,Y,Z Guide rail Linear Square Rail from Taiwan
Control System DSP controller
Driving Step motor (Option: Servo Motor)
Voltage AC380V/50-60Hz
