Price:Negotiable
Brand:zzbqd
Quantity:10

Send Inquiry

Feature
1. Applicable to long-time flow-thru electical control field.
2. Adopting straight-action diaphragm structure ensures safe
start of the normal open solenoid valve without pressure.
3. Choicesof multiple coils and materials provide ideal products for customers.

Tecnology Parameter
Item Parameter
Operating Medium Air,Water,Oil,Gas
Motion Pattern Direct Drive Type
Type Diaphragm Type,Normal Open
Operation Fluid Viscosity 20CS Below
Pressure Difference 0~1.0Mpa
Working Pressure 1.0Mpa
Medium Temperature -5~80?
Environment Temperature -5~60?
Install Method Wantonly
Voltage AC380V,220V,110V,36V,24VDC220V,110V,36V,24V,12V

Specification
Model Port Size Orifice(mm) CvValue PressureDifference(MPa)
2WBCZ-15 G1/2” 16 4.8 0~0.8
2WBCZ-20 G3/4” 20 7.6 0~0.8
2WBCZ-25 G1” 25 12 0~0.8
2WBCZ-35 G11/4” 35 24 0~0.8
2WBCZ-40 G11/2” 40 28 0~0.8
2WBCZ-50 G2” 50 48 0~0.8
