Functions

Small and easy to use

The machines is small and easy to move with simple operation and full function that is very suitable for personal using.

Lcd display

Adopt 5-inch LCD device can display a moving needle tracks.

Emergency buttons

Start, stop and emergency buttons are available.

Support USB

Flash disk supported.

Connect with pc

Can be connected with PC with cable (serial communication).

High speed

The maximum embroidery speed is up to 1000 rpm.

Precision

Stepping control precised to 0.1MM.

Automtic trimmer

The machine automatically cut surface thread and the bottom thread.

Disconnection auto-detection

automatical thread-break detecting. When the face or bottom threads are broken or used up, the machine will detect and stop automatically.

Large Memory

Standard memory of 1,000,000 stitches and up to 99 patterns.

Change color automatically

The machine can be set to automatically change color, auto-start.

Low Power consumption

Power consumption 400W.

Update

Can be updated by downloading software to upgrade the machine procedures, functions increase efficiency and better embroidery

Wind disturbance

Off-line plastic pipe to make smooth, to avoid the wind generated by high-speed vibration or interference, to reduce the resistance.

Auto-around bottom line

A winding device can wrap the bottom line automatically.

Technical Parameter

Model: Autoemb

Head: 1

Needles: 9/12/15

Embroidery area: 330mm X 450mm

Speed: 250- 1000

Stitch length: 0.1- 12.7mm

Machine Size:  760mm(L) X 720mm(W) X 850mm(H)

According to customers different requirements we can make embroidery machine with different specifications
