Technical dateTube Diameter 80-1600mm
Tube Length 120-8000mm
Thickness 0.4-1.2mm(Galvanized steel)
0.4-1.2mm(Stainless steel)
Strip Width 137-140mm
Strip speed 28m/min
Lock seam Outside tube, on the inside on request
Controlling System PLC automatic control
Main motor power 5.5KW
Cutting motor power 5.5KW
Electric 380V/50Hz
(According to customer’s request)
Working pressure 0.5-0.7KMP
Material Galvanized steel0.4-1.2mm
Stainless steel0.4-0.8mm
Aluminum steel0.4-1.2mm
Thickness and Diameter 0.4mm <=500mm
1.2mm =1600mm
Weight about 2800kg
Dimension 3500x2200x2850mm
