Free Ball Float Steam Trap Performance Parameter/ Material List of Main Part:Mini Working Pressure
0.01Mpa
Maxi allowable temperature for cast steel
42 5
Mini degree of super cooling
0
Maxi allowable temperature for stainless steel
525
Leakage rate with loading
0
Working Medium
Saturated vapor, condensed water
Maxi allowable rate of back pressure
80%
Exhaust plant
Stainless steel / alloy
Valve body, cap
WCB / 304
Floating ball
Stainless steel
Valve seat
2Cr13 / 304
Filter
Stainless steel
Free Ball Float Steam Trap Main Basis for Type Selection:
Condensation water loading (discharge)kg/h (select the multiplying power 2~3 times).
Maximum working pressure Mpa
Operation pressure differential
Valve material and nominal pressure
Connection mode and dimension
