Brand:yili machine
Model:-
MOQ:1 Sets
65Mn spring steel notched harrow disc with HRC 38-45
| Common Specifications of Disc | |||
| Dia. | Concavity | Thickness MM | |
| MM | INCH | MM | |
| 255 | 10 | 12 | 3 |
| 305 | 12 | 19 | 3 |
| 330 | 13 | 25 | 3 |
| 355 | 14 | 38 | 3 |
| 410 | 15 | 38~50 | 3 |
| 430 | 17 | 57 | 3,4 |
| 460 | 18 | 38~60 | 3,4 |
| 480 | 19 | 57 | 3,4 |
| 510 | 20 | 44~63 | 3,4,5 |
| 535 | 21 | 63 | 3,4,5 |
| 560 | 22 | 60~85 | 4,5,6 |
| 585 | 23 | 75~90 | 4,5.6 |
| 610 | 24 | 75~95 | 4,5,6 |
| 660 | 26 | 86~115 | 5,6,7,8 |
| 710 | 28 | 100~130 | 5,6,7,8 |
| 760 | 30 | 120~135 | 6,7,8,10,12 |
| 810 | 32 | 120~140 | 8,10,12 |
| 910 | 36 | 120-200 | 8,10,12 |
| 960 | 38 | 120-200 | 8,10,12 |
1. Product Name: Harrow Disc Blade
2. Material: 65MN
3. HRC: 38-45
4. Diameter: 254-810mm
5. Thickness: 3-12mm
6. Edge type: plain, notched
7. Hole: square, round, or combined ones
