Brand:yili machine
Model:1BZ
MOQ:1 Sets
Disc Harrow ( 1BZ hydraulic trailing disc harrow )
Hydraulic heavy duty disc harow for sale
Matched tractor 80-140hp
Working width 2200-5300mm
Working depth 180-200mm
Disc diameter 660mm
Disc Nos. 20/24/28/32/36/48 pcs
Tractor trailed linkage
High quality rubber tire equipped
Main Specifications
| Model | 1BZ-2.0 | 1BZ-2.2 | 1BZ-2.5 | 1BZ-3.0 | 1BZ-3.4 | 1BZ-4.0 | 1BZ-5.3 |
| (m) | 2.0 | 2.2 | 2.5 | 3.0 | 3.4 | 4.0 | 5.3 |
| (mm) | 180~200 | 180~200 | 180~200 | 180~200 | 180~200 | 180~200 | 180~200 |
| | 18 | 20 | 24 | 28 | 32 | 36 | 48 |
| (mm) | 660(650) | 660(650) | 660(650) | 660(650) | 660(650) | 660(650) | 660(650) |
| (kg) | 1200 | 1250 | 1350 | 1450 | 1550 | 1950 | 2530 |
| (kw) | 51 | 59.6 | 59.6~74.6 | 73.5 | 88.2 | 88.2 | 101.5 |
| linkage | (Trailed) | ||||||
