ISO17712 & C-TPAT APPROVE HIGH SECURITY BOLT SEAL JF016
Material
Carbon steel with zinc chromate finish, ABS plastic body on locking case.
Dimensions
8.0mm diameter shaft and 73mm shaft length ; 19.5mm diameter head
Strength Characteristics
Average pull apart force is 4,713 lbs (2,138 kg, 21.0 kN).
Average cutting force (shear) is 5,477 lbs (2,484 kg, 24.4 kN).
Decoration/Printing
Characters are 1/4” (6.35mm) high for easy reading.
Custom seven characters for company name or logo along with max ten consecutive numbers
Colors
Red / Blue / Orange / Yellow / White / Purple / Dark Green / Clear / Neon Yellow
Packaging
Standard Packaging: 20 Bolts/Bag ; 300/Carton
Carton Dimensions:33.5X33.5X12cm
Carton Weight: Gross: 22 kg Net: 21 kg
