Brand:Yuan
Quantity:300
Send Inquiry
Standard technical parametersframework material: SUS304 stainless steel
framework size: 1200*300*1000(mm)
The widest breadth of the passage: 600mm
Weight: 75Kg*2
Power supply: AC220/110 50/60Hz
Driving electromotor: DC electromotor 24v
Input interface: Dry contact signal or +12V level signal or DC12V pulse signal with width of more than 100ms, driving current: >=10mA
Normal life-span: 3million times
Communication interface: RS485 standard Distance less than 1200metres
Card read windows: 2
Windows for overhaul: 4
Transit speed: 30-40 persons/min
Time for opening or closing: 1s
Starting time after power is on: 3s
Automatic reset time after fault: 10s
Working environment: indoor, outdoor (with a tent over)
Temperature: -10?—— 50? Relative humidity: =90% no condensation
