Brand:Yuan
Quantity:200
Send Inquiry
Technical parameters
Housing material:304 stainless steel
Dimension:L1400*W300*H1000mm
Width of glass gate:285mm
Height of glass gate:780mm
Standard passage width:550mm
Net weight:90Kg
Power:24V DC
Frenquency:50/60Hz
Communication interface:RS485
Input interface:Dry contact signal/12V level signal/DC12V pulse signal
Normal life-span:3 million times
Transit speed:40 persons/min
Opening/closing time:1-2 secs
Auto reset time:10 secs
Working environment:Indoor/outdoor
Working temperature:-10C to 50C
Relative humidity:=90% no condensation
