Brand:Winnix
Quantity:1000
Send Inquiry
Main Feature:1. Impinj R2000 chip inside
2. Complies with EPC C1G2 protocol.
3. Working frequency is 840~960MHz, with LBT function.
4. It supports dense reader working mode (DRM)
5. With standard 12dBi antenna, the reading distance can reach 24m, reading speed is 400tags/s.
6. With simple power supply and interface circuit, a high-performance RFID system can be established.
7. It is suitable for logistics, costume, medical industry and complex assets management etc.
8. Passed CE and FCC certification.
Basic Information:
Size(L x W x H): 76.5×39.7×9mm
Weight: 100g(Including heat sink)
DC power: 4.5V~5.5V
Physical Interface: 12pin ZIF interface / FCC cable (Including power, communication, GPIO, USB)
Antenna connector: MMCX with VSWR < 1.5:1 @ 50 ohms
Working temp: -20~+70?
Storage temp: -40~+85?
Relative humidity: 10%~90%RH
