• base material: hot dipped galvanized steel coil with zero spangle, also can be galvalume steel coils/cold rolled steel coils• Quality standard & grade: JIS G3312 CGCC or other standard
• Thickness range: 0.14-3.0mm
• Widths: 914/1,000/1,200/1,219/1,220/1,250mm or other as customer requested.
• Thickness tolerance: +/- 0.02mm
• Width tolerance: +4/- 0mm
• Zinc coating mass: 40-275g/m2
• Painting coating:
o Top coated/back coated: 15-20/5-7 micron, 20-25/5-7 micron
o Coat fabric: 2/1 or 2/2
• Color: According to RAL number or customer’s requirement
• Packing: : Properly packed for ocean exportation in 20ft containers or bulk transportation
• Internal diameter: 508mm
• Coil weight range: 3-10MT
• Shipment: After deposit or L/C at sight, by bulk vessel or by container
