Model WPC124S31 WPC124S32 WPC124S33 WPC124P41Horizontal Resolution 420TVL 480TVL 540TVL 420TVL
Pick-up Device 1/3"SONY Super HAD CCD 1/3"SONY Super HAD CCD 1/3"SONY Super HAD CCD 1/4''SHARP
Scanning Area 4.9mm(H)×3.7mm(V)
Picture Element PAL:752(H)x582(V); NTSC:768(H)x494(V)
TV System PAL/NTSC
Minimum Illumination IR ON 0 lux
S/N Ratio More than 48dB
Auto Electronic Shutter PAL:1/50s-1/100.000s
Gamma Characteristic 0.45
Auto Gain Control Auto
Auto White Balance Auto
Back Light Compensation Auto
Synchronous System Internal Synchronization
Lens Mount Standard 6mm 4/6/8/12/16mm Can choice
Video Output 1.0vp-p.75O,BNG Connector
IR Distance 25 Meters
Protection Rate Ip66
Power Supply DC 12V ±10%
Current Consumption 90mA(IR ON MAX 470mA)
Temperatur -30 ~ +50 C
Material Aluminum alloy
