Image sensors: 1/3 Sony, Sharp, and LG color CCD Horizontal resolution: 420TVL
Resolutions:
PAL: 500 x 580 pixels
NTSC: 510 x 492 pixels
TV system: NTSC/PAL
Scanning system:
PAL: 625 lines, 50fps
NTSC: 525 lines, 60fps
Sync modes: internal synchronization
Minimum illumination: 0.5 lux/F1.2
S/N ratio: >48dB
Video output: 1.0Vp-p, 75O
Electronic shutter: 1/50 to 1/100,000sec
Auto white balance
Power supply: 12V DC
Operating temperature: -10 to +50°C
Humidity: 95% RH
Lens: 3.6mm
Dimensions: 60 x 21 x 21mm
Packing dimensions: 90 x 40 x 40mm
