Brand:CenSee
Send Inquiry
Model: CS-G1401C Size(mm): 40x40x60mm
Specification: 1/3" SONY CCD,420/480/540TVL,0.05Lux,C/CS mount
Specification
Model:
CS-G1401C
CS-G1401CH
CS-G1401CM
Image Device
1/3 “ SONY CCD
Number of Pixels
PAL:500(H)×582(V)
PAL:752(H)×582(V)
PAL:792(H)×582(V)
Scanning System
PAL: 625Lines, 50 Field/Sec
PAL: 625Lines, 50 Field/Sec
PAL: 625Lines, 50 Field/Sec
Horizontal Resolution
420 TVL
480TVL
520 TVL
Horizontal Resolution
0.05 lux
S/N Ratio
=48 dB
Electronic Shutter
PAL : 1/50s ~ 1/100,000s
Gamma Characteristic
0.45
NTSC System
On/Off
White Balance
Auto
Sync System
Available
Video output
1.0Vp-p 75 Ohm
Power
DC 12V
Consumption
100mA
Operation Temperature
-10? ~ + 50?, RH 95% Max
Built-In Lens
C/CS MOUNT (optional)
