Price:Negotiable
Brand:HY
Quantity:2000

Send Inquiry

Electrical Specification
Frequency Range-MHz 2300~2700
Bandwidth-MHz 400
Gain-dBi 12
VSWR =1.5
Horizontal Beam width -° 50
Vertical Beam width-° 35
F/B Ratio-dB =15
Nominal Impedance-O 50
Polarization Vertical
Max. Power-W 50
Connector SMA Male or customized

Mechanical Specification
Antenna Dimension-mm 210×180×45
Weight-kg 0.35
Pole Dimension-mm f40~50
Temperature-? -40~+60
Humidity-? 5~95
