Price:Negotiable
Brand:HY
Quantity:10000

Send Inquiry

Electrical Specification
Frequency Range-MHz 1575.42
Bandwidth-MHz 5
Gain-dBi 28
VSWR =1.5
DC Voltage -V 3-5
Noise Figure -dBi =1.5
Nominal Impedance-O 50
Polarization RHCP
Max. Power-W 50

Mechanical Specification
Cable –mm 1.13 60
Connector IPEX or customized
Antenna Dimension-mm 25×25×7.5
Weight-g 21
Mounting embedded
Temperature-? -40~+60
Humidity-? 5~95
