Wavelength Range--850±40 / 1300±40 nm 1260 ~ 1650 nm
Test Wavelength--850 / 1300 nm ;1310 / 1550 nm
Insertion Loss :
Typ: 0.8dB Max: 1.2 dB
Typ: 0.6 dB Max:0.8 dB
Return Loss:
MM = 30dB SM = 50dB
Crosstalk:
MM = 35dB SM = 55dB
PDL :
=0.05 dB
WDL :
=0.25 dB
Repeatability :
=±0.02 dB
Operating Voltage:
3.0 V or 5.0 V
Durability :
= 10 Million Cycles
Switching Time :
=8ms
Optical Power:
=500 mW
Operating Temperature :
-20 ~ +70 ?
Storage Temperature :
-40 ~ +85 ?
Relative Humidity:
5% ~ 95 %
Weight :
14 g
Dimension:
(L)27.0×(W)12.6×(H)8.2 ±0.2 mm
Note: 1 Within operating temperature and SOP.
2 Excluding Connectors.
