Parameter: Specification Rated lifting weight (kg) Lifting height(m) Lifting speed(m/min Input power(w)
Rated volt(v)
Rated frequency(Hz) NET(kg)
PA200 100 12 10 450 220 50 11.0
PA250 125 12 10 500 220 50 11.5
PA300 150 12 10 550 220 50 12.0
PA400 200 12 10 750 220 50 16.5
PA500 250 12 10 900 220 50 17.0
PA600 300 12 10 1050 220 50 17.5
PA800 400 12 10 1300 220 50 18.5
PA1000 500 12 10 1600 220 50 26.0
REMARK: AS YOUR REQUEST, WE CAN PRODUCE RATED VOLT 110V. Specifications/Features:
1,The emergency stop switch
2,Upper limit function
3,Thermal protection terminal
4,Protection class IP40
5,Insulation class B
6,Work Duty: S3-20%-10min
7,Diameter of wire rope: 3.0mm
8,With copper wire motor under high temperature cannot be burned
