Brand:Antenna
Quantity:800
Send Inquiry
Application: Suitable for railway, VSWR at good performance, RFID system, closed processing, anti-water ability.Characteristic: Wide Angle design. cover a wider range of area. Structure design, enhancement of vibration and impact resistance. Direct ground.
Specifications
Model D900B10120K D860B10120K
Frequency Range (MHz): 902~928 / 865~868
Band Width (MHz): 26 / 3
Gain(dBi): 10
Beam Width E-Plane(°) : 120
Beam Width H-Plane(°): 30
VSWR: =1.5
Polarization: Vertical/ Horizontal
F/B (dB): =20
Max Power(W): 100
Impedance(O): 50
Connector: N-female or user specified
Weight(kg): 4.5
Dimensions(mm): 700×150×90
Radome Material: Fiberglass
