Name&P/N: AT021N2 / 1010210201 Category: GSM
Application: Multi-band wireless terminal
Length(Metric)(mm): 50-100
Weight(g): 0-10
Frequency Range(MHz):
824-894
890-960
1575
1710-1880
1850-1990
1920-2170
2400-2500
Max. Input Power: 20
Gain(dBi): 1-3
Imp.(O): 50
Connector: SMA
Beam Tilt Angle:
Horizontal Half-power Beam Width:(°)
Vertical Half-power Beam Width:(°)
Polarization: Vertical
Frequency Range (MHz)
824-894,890-960,1575,1710-1880,
1850-1990, 1920-2170,2400-2500
Gain(dBi)
1-3
VSWR(max)
3:1
Impedance(Ohm)
50
Connector
SMA male
Polarization
Vertical
Max Input Power (W)
20
Color
Black
Dimensions(mm)
F7.5×77.5×17
Weight(g)
6
Relevant products: AT025N10,AT005N3, AT007N2, 2JW034(2J s.r.o.), 2J010( (2J s.r.o.)
