Price:Negotiable
Brand:Aristone

Send Inquiry

Item (Donor Unit)
Downlink
Uplink


Frequency Range (MHz)
GSM
935~960
GSM
890~915

DCS
1805~1880
DCS
1710~1785

CDMA
869~894
CDMA
824~849

PCS
1930~1990
PCS
1850~1910

CDMA450
460~470
CDMA450
450~460
Bandwidth(MHz)
(Under Request)
(Under Request)
Output Power (dBm)
33±2
-5±2
Max Gain (dB)
50±3
45±3
ATT Adjustment in 1 dB Steps
0~30
0~30
Frequency Error (ppm)
=0.05
=0.05
Noise Figure(dB)
-
=5
VSWR
=1.5
=1.5
Delay(uS)
=5
=5
? (for CDMA)
>0.95
>0.95
RF Connector
N(f)
Impedance(O)
50
Power Supply (V)

Temperature(?)
-40~+55
Humidity (%)
=95
Monitor Access Options
RS-232, Wireless Modem
Dimensions (mm)
500×400×220
Weight (kg)
30
