Item
Downlink
Uplink



Frequency Range (MHz)

GSM
935~960
GSM
890~915

DCS
1805~1880
DCS
1710~1785

CDMA800
869~894
CDMA800
824~849

PCS
1930~1990
PCS
1850~1910

CDMA450
460 ~ 470
CDMA450
450 ~ 460

WCDMA
2110~2170
WCDMA
1920~1980
Bandwidth(MHz)
(Under Request)
(Under Request)
Max Output Power (dBm)
40±2
33±2
Max Gain (dB)
95±3
90±3
ATT Adjustment in 1 dB Steps
0~30
0~30
Frequency Error (ppm)
=0.05
=0.05
Noise Figure (dB)
=5
=5
VSWR
=1.5
=1.5
Delay (µS)
=5.0
=5.0
? (for CDMA)
>0.95
>0.96
Spectrum Emission Mask(for WCDMA)
Meets 3GPP
RF Connector
N(f)
Impedance (O)
50
Power Supply (V)
,45~55Hz
Temperature (?)
-40~+55
Humidity (%)
=95
Monitor Access Options
RS-232, Wireless Modem
Dimensions (mm)
550×420×240
Weight (kg)
39.5
