cutting area mm(M*L) 2000*2000 and 2000*3300
The maxthickness of the materials (after be absorbed)  max. 50mm
mechnical speed      max.45m/min
the way of cutting   up and down repeated movement style
power              AC 380N/50 Hz    Max.60KW max.36KW
Air compressor  0.55Mpa
air pressure      5.5kgf/cm2
air flow            160NL/min
the way of connecting CAD and CAM    Net/software disk/bar code
blade sharpening system                    double-wheeled disrotating
total weight (KG)            2200
