Brand:-
Model:-
MOQ:-0 -
Send Inquiry
Today Standard Precision Machine Tool Co.,Ltd is a professional China high speed vertical machining center v-8 manufacturer, we are able to offer you best and cheap high speed vertical machining center v-8 and high speed vertical machining center v-8 for sale.Advantage ●Lathe body used first class iron,rigidity and wide base,can ensure the machine durable and never deform●Powerful direct spindle with 10000rpm speed●High static quality equibrium distribution and show optimum dynamic performance●3 axle rapid travel speed 40m/min,reduced processing time.●High speed synchronous tool changing, stable and fast, and cut down the non processing time.●Applied on processing of 3C accessories,Automotive,Hardware,watches,clocks, electronic communications, mobile phone accessories, etc.Main Specification ●Main Spindle Speed:10000 rpm●Main Spindle Power:7.5KW●Main Spindle Type:BT40●XYZ Travel: 800 x 500 x 530●Tools quantities: 24●Rapid Feed Speed: 40/40/30m/min●Table Size:900 x 450Main Configuration ●Japan's MITSUBISHI, FANUC or SIEMENS control system in Germany for optional●Japan's MITSUBISHI, FANUC or SIEMENS spindle motor, motor and drive shaft three●Taiwan famous brand spindle●Taiwan PMI/HIWIN, or Japanese THK or Germany Rexroth guide rail and ball screw●Taiwan famous brand 16T turnover type knife tool library●Japan's NSK bearingTechnical Specification Lathe parameterV-6V-8Work TableWorktable Area700 x 420900 x 450T-Slot3-14H83-14H8T-Slot Diatance125125RangeX-axle Range600800Y-axle Range400500Z-axle Range400530Distance from Spindle Center to Column500580Distance from Spindle to work table130--660130-660SpindleSpindle TypeBT40BT40Spindle Power5.5KW7.5KWSpindle Speed10000rpm10000rpmFeedMax.Feed Speed10000 mm/min10000mm/minRapid Travel Speed(x/y/z)48/48/48m/min40/40/30m/minKnife Tool LibraryTypeDisc TypeDisc TypeTool quantities2024Tool Change Time--LocalizationPrecision Localization Accuracy±0.005/300±0.005/300Rapeat Localization Accuracy±0.003/300±0.003/300SizeL*W*H2000 x 2700 x 24002500 x2400 x 2600WeightMax Load Capacity350kg450kgMachine Weight3500kg4500kgStandard ConfigurationNameOriginBrandRemarkLathe bedChinaHigh strength dense cast iron (first class HT300), two aging treatmentNC SystemJapanMISUBISHIM70Guide railRexrothBall ScrewTaiwanPMI/hiwinKnife Tool LibraryDisc type with 20/24 toolsSpindleTaiwanCentralized LubricationTaiwanCooling SystemLarge Flow Cooling SystemSpindle CoolingOil CoolerGuide Rail ProtectionX/Y/Z alxe Stainless Steel ProtectionCommunication InterfaceCF Card/USB interfaceOptional ConfigurationQuality Assurance Some Samples
