Frequency range: 2MHz~40MHz
Initial calibration tolerance (@25℃±2℃): ±1ppm typical
Frequency stability vs operation Temp. Range: +/-2ppm
Operation temperature range: -40~70C
Aging/year: ±1ppm
Supply voltage: 5V,9.0V,12V,15V
Current consumption: 20mA max
Output : Clipped Sine, 7dBm min @ Load 50Ω
         HCMOS
Start-up time: 2ms max
Frequency tuning range: ±3ppm typical by internal trimmer
Frequency voltage control range: ±50~200ppm
Control voltage range 2.5V±2V
Linearity 10% max
Storage temperature range -55~+85℃
Package: DIP14,25×15×10.0 mm
