Brand:BCE
Model:57x48x34cm
MOQ:2 Pieces
Send Inquiry
- Frequencies: 5MHz and 10MHz
- Stability: 5E-15/℃
- Frequency drift: 5E-15/Day
- Supply voltage: 85~264VAC
- External DC input: 22 to 28 VDC
- Peak power:110W max
- Steady state @ 25℃: 90W min
- Output wave form: sine
- Output level:
- 5MHz: 12dBm min
- 10MHz: 12dBm min
- Load: 50Ω
- Power source sensitivity: 1.0E-14/V
- Synthesized frequency resolution: 1.0E-15
- Magnetic sensitivity: 1.0E-14/Gauss
- Timing output:
- Format: 1PPS (positive going pulse)
- Amplitude: 3 V - 5V (TTL compatible)
- Pulse width: 10μs - 20μs
- Rise time: 10ns
- Jitter: 100ps RMS
- Short term stability:
- 5E-13/S
- 1E-13/10S
- 2E-14/100S
- 8E-15/1000S
- Phase noise:
- Outputs 5MHz
- 1Hz: ≤-105dBc
- 10Hz: ≤-120dBc
- 100Hz: ≤-140dBc
- 1KHz: ≤-150dBc
- 10KHz: ≤-150dBc
- Size: 57x48x34cm
- Weight: 120 lbs (55kg)
