Brand:BCE
Model:DIP14, 20.2 × 12.8 × 10mm
MOQ:10 Pieces
Send Inquiry
Frequency: 10 to 40MHz
Initial calibration tolerance (at 25℃ ±2℃): ±1ppm typical
Frequency stability VS operating temperature range: ±0.28ppm Operating temperature range: -40 to 85°C
Aging: ±1ppm
Supply voltage: 5.0, 8 and 12V
Current consumption: 20mA (maximum)
Output: TTL and CMOS
Start-up time: 2ms (maximum)
Frequency tuning range: VCTCXO only frequency tuning range: ±5ppm min
Control voltage range: 2.5V ±2V
Linearity: 10% (maximum)
Storage temperature range: -55 to 85℃
Packaging: DIP14, 20.2 × 12.8 × 10mm
