Brand:BCE
Model:SMD 3.2x 2.5x1.0mm
MOQ:20 Pieces
Send Inquiry
- Frequency range: 8.192 to 40MHz
- Initial calibration tolerance (at 25 ±2℃): ±1ppm (typical) Frequency stability: ±1.0ppm
- Operating temperature range: -30 to 85°C
- Aging: ±1ppm
- Supply voltage: 2.5 to 3.3V
- Current consumption: 6mA (maximum)
- Output: TTL/CMOS
- Clipped sine, 0.8Vp-p minimum at 10kΩ//10pF load
- Start-up time 2ms (maximum)
- VCTCXO only frequency tuning range: ±5 to ±20ppm, ±10ppm (typical) Control voltage range: 1.5 ±1V
- Linearity: 10% (maximum)
- Phase noise: -135dBc/1kHz
- Storage temperature range: -40 to 85℃
- Package: SMD 3.2x 2.5x1.0mm
