Launch BST-760 is auto battery health status test tool. BST-760 battery health test come with main unit and 2 batteries. Launch battery system tester can quickly repair vehicle trouble.

Launch BST-760 battery health test Launch battery system tester
Launch BST-760 Battery Health tester BST 760 Auto Battery test

Launch BST-760 battery tester mainly function

Launch BST-760 battery tester can detect common faults of both starting and generator charging systems, which help maintenance personnel to achieve quick repair to the vehicle trouble.

Launch BST-760 Battery Health tester can easily, quickly and accurately measure the actual cold cranking current capability to judge the health status of the battery itself.

Launch BST-760 Language: Chinese, English, Russian

BST-760 Battery Tester Scope: Suitable for 6V & 12V battery system and 12V & 24V starting and charging system detects

Launch BST-760 battery tester Advantage:

Eight lines with backlight LCD display and humane language prompted interface
Simple, secure , fast , and accurate display test results ( the test takes about 3 seconds)
Does not emit light , no heat , no discharge , no spark , no operating dangerous
Configuration 0-900A AC and DC current clamp
Built - in thermal printer
Can store 100 groups of test results
Automatic temperature compensation function
With ripple voltage test function
Dedicated Kelvin test clip
Powerful auxiliary functions
Replaceable test lines
BST-760 Battery Tester Advanced functionality:
Directly detected in the car , do not need t remove the battery
Applicable to a variety of models, all kinds of batteries , and a variety of system mode
Directly test the battery of the loss of electricity , bad cell battery
Testable starting / charging current
Advanced starter / alternator detection

Launch BST-760 Specification:

1. The structure size : 110 * 240 * 50mm;
2. Shell ABS anti-acid plastic , soft rubber TPU corrosion-resistant package , two-color molding ;
3. 128 * 64 dot matrix , large backlit display screen (3 inches ) , adjustable brightness LCD display ;
4. The configuration of the 0-900A AC and DC current clamp ;
5. Built-in thermal printer , the test results can be printed out at any time ;
6. Can store 100 groups of test results data , ready at any time to view and print any of a group of test data ;
7. Test standards , including the most commonly used battery standard , such as CCA, BCI, CA, MCA, JIS, DIN, IEC , EN , SAE , GB ;
8. Operating Temperature : -20-55  /-4-131

Powerful auxiliary functions:

View / Print
Ammeter Function
Thermometer
QC mode
License plate number input function
Time and time format Adjustment
User information input
Display backlight brightness adjustment function
Print sharpness adjustment
Standby power function

BST-760 Battery Test criteria and scope:

CCA 100-2000 (SAE & BCI to develop the standard most commonly used : the cold-start battery rating )
BCI 100-2000 ( international battery Committee standards )
CA 100-2000 ( when the effective starting current rating)
MCA 100-2000 ( ships standard effective starting current rating )
JIS 26A17 - 245H52 ( Japanese Industrial Standard)
Standard DIN 100-1400 ( German Automobile Industry Committee )
The IEC 100-1400 ( International Electrotechnical Commission standard )
EN 100-2000 ( European Automobile Manufacturers Association standards )
SAE 100-2000 ( U.S. Engineers Standard)
GB 100-1400 ( Chinese National Standard )

Launch BST-760 Battery Health Tester Function:

Launch BST- 760 has 2 battery: one is used on the host, You can use BST-760 Auto Battery test tool even without this battery but will not have backup power supply function. the other battery is used on Detachable clamp. The backup power supply function is the 15th auxiliary function. Some luxury vehicle ECU Power can't be cut.If the power failure,it will be locked. So when change storage-battery for luxury vehicle, BST-760 can supply power to ECU.

BST-760 Test tool Package including:

1pc x BST-760 Battery Health Tester Main unit
1pc x Tester cable
1pc x Detachable clamp
1pc x User's Manual
1pc x Carry case
