Include:

One pump,popular in the international market

Inner ultrasonic device

Cabinet and cover

Standard fuel injector connectors

Test fluid: 2 bottle (1L/bottle)

Cleaning fluid: 1 bottle (1L/bottle)

Packing:0.63m×0.58m×1.52m=0.73m3

Weight: 80kg

Technical data

Test the injecting state of six injectors at same time.

RPM: 0-9950R/min             step: 50r/min

Pulse width: 0-20ms          step: 0.1ms

Time: 0-9950                    step: 5s

Count: 0-9950                  step: 50 times

System pressure: 0-6.5kg/cm2( adopt Bosch pump)

Features

1.Optinal cleaning effect by powerful ultrasonic technique.

2.Adopt unique infinitely variable pressure adjustment.

3.Feature with protective device for pump overtime running.

4.Simulate nine running states of engine for choice.

5.Unique built-in LED backlight, easy to observe.

6.Suit to test the high/low resistance,voltage/current injectors.

7.Time or count test mode for choice.

8.Returning the test fuel by solenoid valve or hand.

9.Build-in two stage filter system for test fuel.

10.Ultrasonic device in the drawer.

11.Sharp design for anti-dirt cover.
