Technical Data

Test the injecting state of six injectors at same time

RPM: 0-9950r/min     step:50r/min

Pulse width: 0-20ms    step:0.1ms

Time: 0-9950          step:5s

Count: 0-9950         step:50 times

System pressure: 0-6.5kg/cm2 (Adopt Bosch double pump)

Feauture

1.Optional cleaning effect by powerful ultrasonic technique.

2.Adopt unique infinitely variable pressure adjustment.

3 Feature with protective device for pump overtime running.

4.Imitated nine running state of engine for choice.

5.Unique built-in LED back light, easy to observe.

6.Suit to test the high/low resistance, voltage/current injectors.

7.Time or count test mode for choice.

8.Returning the test fuel by solenoid valve.

9.Build-in two stage filter system for test fuel.

10.Left  External ultrasonic device.
