Outside dimension：

 L7550*W3550*H3150mm

Inside dimension：

L6300*W3450*H2700mm

Plenum dimension：

 L6400*W3550*H450mm

basement：

without basement and floor

Illumination system：

 ceiling light：36W*4*8units=32pcs；power：1.15KW

Glass：

tempered glass

Air inlet system：

5.5kw one set inner motor centrifugal fan with air volume 15400m3/h

Air outlet system：

4kw one set inner motor centrifugal fan with air volume 14000m3/h

Cabin system：

 1. air intake plenum is made of cold-rolled sheets

 2. ceiling boards are made of galvanized steel sheets

 3. PVC manual curtains around the sides and slipping on the aluminum alloy rails

 4. 50mm EPS panels at the back wall

Generator system：

 rear exhaust；square tube frame；power coated

Heat system：

one set Riello G10 burner with max heat capacity：100000kcal/h

 one set stainless steel heat exchanger

Filtration system：

primary filter；ceiling filter；glass fiber filter

Control system：

controls fan, electric damper, burner and illumination only

Installation way：

 sling hoist or square tube support

Voltage frequency：

 380V/3P or 220V/1P, 50Hz

Total power：

11.5KW
