Application:EJ20Impreza/WRX/STI

WRX/STI - TD05H-16G

Complete Turbo Compressor Turbine

SYSTEM Journal Bearing A/R 49 Nozzle Area 7 cm2

MODEL TD05H-16G Wheel Dia. 48.3/68 mm Wheel Dia 49.2/56 mm

P/N S5167 CFM 580

Application EJ20Impreza/WRX/STI Actuator 0.9 Bar

MAX HP 380+ HP

WRX/STI - TD05H-18G

Complete Turbo Compressor Turbine

SYSTEM Journal Bearing A/R 49 Nozzle Area 8cm2

MODEL TD05H-18G Wheel Dia. 50.5/68mm Wheel Dia 49.2/56 mm

P/N S5188 CFM 590

Application EJ20Impreza/WRX/STI Actuator 0.9 Bar

MAX HP 420+ HP

WRX/STI - TD05H-20G-1

Complete Turbo Compressor Turbine

SYSTEM Journal Bearing A/R 49 Nozzle Area 7cm2

MODEL TD05H-20G-1 Wheel Dia. 52.6/68 mm Wheel Dia 49.2/56 mm

P/N S5207 CFM

Application EJ20Impreza/WRX/STI Actuator 0.9 Bar

MAX HP 430+ HP
