Truck Tire Changing Machines

Specification:

Rim diameter: 14"-26"
Max.wheel weight: 500kg
Max.wheel width: 780mm
Max.wheel diameter: 1600mm
Hydraulic pump motor: 1.5KW
Geaxboxmotor: 1.8Kw
Operation control voltage: 24V
Bead breaker force: 2500Kg
Noise level: <70dB
Package size(mm): 2030×1600×1000
Weight: 570/650kg

Features:

1.Semi-automatic universal truck tire changer,
2.All movements of the working parts are guide by the movable control platform,
3.particulary suitable for handling truck wheels,farm wheels,passenger car wheels and industrial vehicle wheels between 14"-26"
4.Four-jaw universal chuck
5.movable control unit
6.Locking jaws with different gripping possibilities
7.Hydraulic motor with pressure regulating device
8.Working arm with quick rotation system
