Brand:THOR
Model:ST-CL735
MOQ:1 Sets
Send Inquiry
| Specification | |
| Lifting capacity | 3500kg |
| Lifting height | 1500mm |
| Second lifting height | 350mm |
| Minimum height | 200mm |
| Platform length | 4200/4500mm |
| Second platform length | 800-1200mm |
| Platform width | 500mm |
| Total width | 3280mm |
| Lifting time | 50s |
| Net weight | 1200kg |
| Gross weight | 1250kg |
Features:
1.With second lifting trolley, equipped with a extended tail skid.
2.Equipped with pneumatic safe insurance device, To ensure that different
lifting height in absolute security.
3.Hydraulic system is equipped with overload protection device to prevent
pressure exceed the maximum safe limit.
4.Secondary lifting hydraulic electric control lock.
