Introduction

1. Inner Screw Copper Tube & Aluminum Fin Design;

2. High Cooling Capacity & Reliable Performance based on World Top Brand Components;

3. Strong Area Adaptability, Even Work Well in Desert.

4. Stream Line Appearance Apply on Wide Vehicle Range;

5. ISO9001, CE&TS16949 Certificaation;

6. Windely Applied on Truck Cab, Trailer, Forklift, Crane & Mining Machine;

Technical Parameters:

Cooling capacity   3010Kcall/h 3.5KW/12000BTU

Compressor         SD5H14/5H14(135CC/R)

Compressor Weight  5.6KG

Voltage            DC12V/24V

Power Consumption  Less than 250W

Condenser Fan QTY      1

Evaporator Blower QTY   1

Refrigerant         R134A(0.9KG)

Total current         Less than 11A(24V)

Dimension          750*680*170MM
